Product Summary

The LM2676SX-5.0 is a regulator. It provides all of the active functions for a stepdown switching regulator capable of driving up to 3A loads with excellent line and load regulation characteristics.

Parametrics

LM2676SX-5.0 absolute maximum ratings: (1)Input Supply Voltage: 45V; (2)ON/OFF Pin Voltage: -0.1V to 6V; (3)Switch Voltage to Ground: -1V to VIN; (4)Boost Pin Voltage: VSW + 8V; (5)Feedback Pin Voltage: -0.3V to 14V; (6)Power Dissipation: Internally Limited.

Features

LM2676SX-5.0 features: (1)Efficiency up to 94%; (2)Simple and easy to design with (using off-the-shelf external components); (3)150 mΩ DMOS output switch; (4)3.3V, 5V and 12V fixed output and adjustable (1.2V to 37V ) versions; (5)50μA standby current when switched OFF; (6)±2%maximum output tolerance over full line and load conditions; (7)Wide input voltage range: 8V to 40V; (8)260 KHz fixed frequency internal oscillator; (9)-40 to +125℃ operating junction temperature range.

Diagrams

LM2676SX-5.0 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
LM2676SX-5.0
LM2676SX-5.0

National Semiconductor (TI)

Switching Converters, Regulators & Controllers

Data Sheet

0-500: $1.78
500-1000: $1.43
1000-5000: $1.37
LM2676SX-5.0/NOPB
LM2676SX-5.0/NOPB

National Semiconductor (TI)

Switching Converters, Regulators & Controllers HIGH EFF 3A STEP- DOWN VLTG REG

Data Sheet

0-1: $3.01
1-25: $2.42
25-100: $2.20
100-250: $1.99
250-500: $1.78
