Product Summary

The TB0640L is a surface mount thyristor.

Parametrics

TB0640L absolute maximum ratings: (1)Non-Repetitive Peak Impulse Current: 30 A; (2)Non-Repetitive Peak On-State Current: 15 A; (3)Junction Temperature Range: -40 to +150 °C; (4)Storage Temperature Range: -55 to +150 °C; (5)Thermal Resistance, Junction to Lead: 30 °C/W.

Features

TB0640L features: (1)30A Peak Pulse Current @ 10/1000ms; (2)150A Peak Pulse Current @ 8/20ms; (3)58 - 320V Stand-Off Voltages; (4)Oxide-Glass Passivated Junction; (5)Bi-Directional Protection In a Single Device.

Diagrams

TB0640L block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
TB0640L
TB0640L

Other


Data Sheet

Negotiable
TB0640L-13
TB0640L-13

Diodes Inc.

Sidacs 30A 58V

Data Sheet

Negotiable
TB0640L-13-F
TB0640L-13-F

Diodes Inc.

Sidacs 30A 58V

Data Sheet

0-1950: $0.26
1950-3000: $0.24
3000-6000: $0.22
6000-12000: $0.21
