Product Summary
The 74LVXC3245MTCX is a Low Voltage Quad 2-Input NAND Gate with 5V Tolerant Inputs. The inputs tolerate voltages up to 7V allowing the interface of 5V systems to 3V systems.
Parametrics
74LVXC3245MTCX absolute maximum ratings: (1)Supply Voltage: -0.5 to +7.0 V; (2)DC Input Voltage: -0.5 to +7.0 V; (3)DC Output Source/Sink Current: ±50 mA; (4)DC Supply Current per Supply Pin: ±100 mA; (5)DC Ground Current per Ground Pin: ±100 mA.
Features
74LVXC3245MTCX features: (1)5V tolerant inputs; (2)2.3V–3.6V VCC specifications provided; (3)5.2 ns tPD max (VCC = 3.3V), 10 mA ICC max; (4)Power down high impedance inputs and outputs; (5)±24 mA output drive (VCC = 3.0V); (6)Implements patented noise/EMI reduction circuitry; (7)Latch-up performance exceeds 500 mA.
Diagrams
