Product Summary

The AD976ARZRL is a 6-bit, high speed, analog-to-digital converter with ECL compatible outputs and a bipolar input stage. The AD976ARZRL is fabricated in a high performance bipolar process that allows encode rates up to 77 MSPS.

Parametrics

AD976ARZRL absolute maximum ratings: (1)Positive Supply Voltage: 0.3 V to +6 V; (2)Negative Supply Voltage: 6.0 V to +0.3 V; (3)Analog-to-Digital Ground Voltage Differential: 0.5; (4)Analog Input Voltages (AIN, +VREF, –VREF): +3 V; (5)Differential Reference Voltage (+VREF to –VREF): 6 V; (6)Digital Output Current: 20 mA; (7)Power Dissipation (+25°C Free Air): 745 mW.

Features

AD976ARZRL features: (1)77 MSPS Encode Rate; (2)Bipolar Input Range; (3)Low Error Rate; (4)Overflow Bit; (5)MIL-STD-883 Compliant Versions Available.

Diagrams

AD976ARZRL block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AD976ARZRL
AD976ARZRL

IC ADC 16BIT 100KSPS 28SOIC
Data Sheet
