Product Summary
The GL827S-MNG is a highly-compatible, low cost USB 2.0 to ATA / ATAPI bridge controller, which integrates Genesys Logic own design high speed UTMI (USB 2.0 Transceiver Macrocell Interface) transceiver.
Parametrics
GL827S-MNG absolute maximum ratings: (1)DC supply voltage: +3.0 +3.6 V; (2)DC input voltage: -0.3 VCC + 0.3 V; (3)DC input voltage range for I/O: -0.3 VCC + 0.3 V; (4)DC input voltage for USB D+/D- pins: -0.3 VCC + 0.3 V.
Features
GL827S-MNG features: (1)Embedded USB 2.0 UTMI transceiver; (2)Embedded 7.5 MIPS RISC CPU; (3)ROM size: 4k words; RAM size: 128 bytes; (4)Supports Power Down mode and USB suspend indicator; (5)Supports USB 2.0 TEST mode features; (6)12MHz external clock to provide better EMI3.3V power input.
Diagrams
 |
