Product Summary

The LM1085ISX-5.0 is a 3A Low Dropout Positive Regulator. Application areas of the LM1085ISX-5.0 include High Efficiency Linear Regulators, Battery Charger, Post Regulation for Switching Supplies.

Parametrics

LM1085ISX-5.0 absolute maximum ratings: (1)Junction Temperature (TJ)(Note 3): 150°C; (2)Storage Temperature Range: -65°C to 150°C; (3)Lead Temperature: 260°C, to 10 sec; (4)ESD Tolerance (Note 4): 2000V.

Features

LM1085ISX-5.0 features: (1)Available in 3.3V, 5.0V, 12V and Adjustable Versions; (2)Current Limiting and Thermal Protection; (3)Output Current 3A; (4)Line Regulation 0.015% (typical); (5)Load Regulation.

Diagrams

LM1085ISX-5.0 block diagram
