Product Summary
The VUO160-08NO7 is a Three Phase Rectifier Bridge. Application areas of the VUO160-08NO7 include Supplies for DC power equipment, Input rectifiers for PWM inverter.
Parametrics
VUO160-08NO7 absolute maximum ratings: (1)IdAV TC = 100°C, module 175 A; (2)IdAV TA = 35°C(RthCA = 0.2 K/W), module 139 A; (3)IFSM TVJ = 45°C; t = 10 ms (50 Hz), sine 1800 A; (4)IFSM VR = 0 t = 8.3 ms (60 Hz), sine 1950 A.
Features
VUO160-08NO7 features: (1)Package with screw terminals; (2)Isolation voltage 3000 V; (3)Planar passivated chips; (4)Blocking voltage up to 1800 V; (5)Low forward voltage drop.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 VUO160-08NO7 |
Ixys |
Bridge Rectifiers 160 Amps 800V |
Data Sheet |
Negotiable |
|
||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||
|
VUO100 |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
VUO100-08NO7 |
Ixys |
Bridge Rectifiers 100 Amps 800V |
Data Sheet |
Negotiable |
|
||||
|
VUO100-12NO7 |
Ixys |
Bridge Rectifiers 100 Amps 1200V |
Data Sheet |
Negotiable |
|
||||
|
VUO100-14NO7 |
Ixys |
Bridge Rectifiers 100 Amps 1400V |
Data Sheet |
Negotiable |
|
||||
|
VUO100-16NO7 |
Ixys |
Bridge Rectifiers 100 Amps 1600V |
Data Sheet |
Negotiable |
|
||||
|
VUO105 |
Other |
|
Data Sheet |
Negotiable |
|
||||
