Product Summary

The ST1S10PHR is a monolithic synchronous step-down regulator. The ST1S10PHR operates with an input supply range from 2.5 V to 18 V and provides an adjustable output voltage from 0.8 V (VFB) to 0.85VIN_SW [VOUT = VFB(1+R1/R2)]. It operates either at a 900 kHz fixed frequency or can be synchronized to an external clock (from 400 kHz to 1.2 MHz).

Parametrics

ST1S10PHR absolute maximum ratings: (1)VIN_SW Positive power supply voltage: -0.3 to 20 V; (2)VIN_A Positive supply voltage: -0.3 to 20 V; (3)VINH Inhibit voltage: -0.3 to VIN_A V; (4)VSW Output switch voltage: -0.3 to 20 V; (5)VFB Feedback voltage: -0.3 to 2.5 V; (6)IFB FB current: -1 to +1 mA; (7)Sync Synchronization: -0.3 to 6 V; (8)TSTG Storage temperature range: -40 to 150 ℃; (9)TOP Operating junction temperature range: -25 to 125 ℃.

Features

ST1S10PHR features: (1)Step-down current mode PWM regulator; (2)Output voltage adjustable from 0.8 V; (3)Input voltage from 2.5 V up to 18 V; (4)2% DC output voltage tolerance; (5)Synchronous rectification; (6)Inhibit function; (7)Synchronizable switching frequency from 400 kHz up to 1.2 MHz; (8)Internal soft start; (9)Dynamic short circuit protection; (10)Typical efficiency: 90%; (11)3 A output current capability; (12)Stand-by supply current: max 6 μA over temperature range; (13)Operative junction temp: from -25℃ to 125℃.

Diagrams

ST1S10PHR block diagram
